Aluminium 5083 Channels

Aluminium 5083 Channels are manufactured from Aluminium Alloy 5083, a non-heat-treatable aluminium–magnesium alloy widely recognized for its exceptional corrosion resistance, excellent formability, and higher strength than 5xxx series alloys. This alloy offers outstanding resistance to marine environments, saltwater, and industrial chemicals, making it an ideal choice for applications where durability, structural integrity, and long service life are critical. Aluminium 5083 Channels provide good machinability and excellent forming characteristics, allowing efficient fabrication through bending, cutting, drilling, rolling, and welding processes. Although the alloy is not heat-treatable, it achieves high strength through work hardening and delivers stable mechanical performance with excellent surface finish. Aluminium 5083 Channels are commonly supplied in O, H111, H112, H116, and H321 tempers, ensuring consistent dimensional stability and reliable performance across industrial and marine applications. Aluminium 5083 Channels are widely used in marine vessels, shipbuilding, architectural components, pressure vessels, chemical equipment, transportation structures, HVAC systems, storage tanks, and general fabrication works. Their superior corrosion resistance, high strength, lightweight nature, and excellent weldability make them especially suitable for harsh environments exposed to seawater, chemicals, and extreme weather conditions. We supply Aluminium 5083 Channels in custom sizes, lengths, thicknesses, tempers, and surface finishes as per client specifications, ensuring precise dimensional accuracy, consistent quality, and compliance with international standards for marine, industrial, architectural, and commercial channel applications.

Aluminium Alloy 5083 Channels Specification

Standards : ASTM B221, ASTM B209M, EN 573, EN 485
Thickness : 0.9 mm – 7 mm
Width : 10 mm to 200 mm (Custom Channel Profiles Available)
Length : : Up to 6.5 meters (Coated & Anodized), up to 5 meters (Mill Finish)
Finish : Mill Finish, Customer-Specific Finish
Type : Hot-Rolled (HR) / Cold-Rolled (CR)
Temper : O, H111, H112, H116, H321
Surface : Anodized, Polished, Brushed, Matte, Sand Blasted, Powder Coated, PVDF Coated

KEY FEATURES

Marine corrosion resistance, high strength, cryogenic capability, excellent weldability, high fatigue resistance, superior performance in aggressive environments.

PRODUCT RANGE

5083 channel in O/H111/H116/H321 marine-grade conditions

GLOBAL EQUIVALENTS

AA5083 (USA), ASTM B209/B928 5083, UNS A95083, AMS 4019, EN AW-5083, EN 573-3, EN 485-2/4, ISO AlMg4.5Mn0.7, EN Numeric: 54300 (Europe/China), DIN AlMg4.5Mn / Werkstoff 3.3547 (Germany), BS N8 / Grade 5083 (UK), AFNOR A-G4.5 (France), UNI 5083 (Italy), JIS H4000 A5083, JIS H4040 A5083-H116/H321 (Japan), GB/T 3190 5083, 54300 China Equivalent, A5083P, LF21 (China), KS D6701 5083 (Korea), TSE EN 5083 (Turkey), SANS EN 5083 (South Africa), NMX-H Marine 5083 (Mexico), IS 5082 (India – Correct Standard), IS 737, IS 736, Hindalco 5083, Jindal 5083, Russian equivalents: AMg5, AMg5M, 5083 Russian equivalent, GCC equivalents: 5083 UAE grade, 5083 Oman grade, 5083 Saudi grade.

TEMPERS

5083-O, 5083-H111, 5083-H112, 5083-H12, 5083-H116, 5083-H321, 5083-H32, 5083-H34.

INDUSTRY APPLICATIONS

Marine structures, shipbuilding plates, boat hulls, defence armour plates, pressure vessels, cryogenic tanks, LNG storage, transport equipment.

BUYER KEYWORDS

5083 channel dealer, 54300 channel supplier, 5083 marine alloy buyer, 5083 armour plate importer, bulk 5083 purchase.

LOCATION KEYWORDS

5083 channel Mumbai, 5083 channel Pune, 5083 channel Delhi, 5083 channel Chennai, 5083 channel Bengaluru, 5083 channel Hyderabad, 5083 channel Ahmedabad, 5083 channel Surat, 5083 channel Dubai, 5083 channel Abu Dhabi, 5083 channel Doha, 5083 channel Riyadh, 5083 channel Muscat.

Aluminium Alloy 5083 Channel – Equivalent Grades

European Standard	BS (OLD)	USA (AA)	Germany (DIN)	ISO	IS	Canadian
EN AW-5083	—	5083	AlMg4.5Mn0.7 (DIN 3.3549)	AlMg4.5Mn0.7	IS 5083 – 5083	5083

Chemical Composition Of Aluminium Alloy 5083 Channels :

Alloy	Fe	Si	Mg	Mn	Cu	Zn	Ti	Cr	Each	Al
5083 (min)	—	—	4.0	0.4	—	—	—	0.05	0.05	remainder
5083 (max)	0.40	0.40	4.9	1.0	0.10	0.25	0.15	0.25	0.15	remainder

Mechanical Properties Of Aluminium Alloy 5083 Channels :

Alloy	Temper	UTS (MPa)		% Elongation
Alloy	Temper	Min	Max	0.5 mm – 0.8 mm	0.81 mm – 1.30 mm	1.30 mm – above
5083	O	175	215	18	20	22
	H32	275	325	10	12	14
	H34	280	335	8	10	12
	H36	290	345	6	8	10
	H38	300	360	5	6	8

Physical Properties of Aluminium 5083 Channel

Properties	Metric
Density	2.66 Mg/m³
Melting Point	590°C – 638°C
Specific Heat (100°C)	880 J/kg·K
